MH Tipping Cylinder MHE129-3-3880

Hydraulic Tipping Cylinder – 3880 mm Stroke

This medium-duty hydraulic tipping cylinder is engineered for efficient and powerful operation in dump trucks and trailers. With a stroke of 3880 mm and 200 bar max pressure, it delivers reliable lifting performance for a wide range of tipping applications.

• Stroke: 3880 mm

• Maximum Pressure: 200 bar

• Oil Volume: 37 L (Working Volume)

• Cylinder Weight: 145 kg

• Tipping Capacity: 32 to 56 tons

Key Features:

• Optimized for 2- to 3-axle dump bodies and tipping trailers

• Lightweight yet powerful for fast cycle times


• Built for high-pressure systems in tough working conditions

Part of the RHINO Series by MH Hydraulics – known for its rugged construction and reliable performance.

Now available from stock at HFI branches in Dammam and Riyadh.
🛒 Browse full specs or place your order: https://hfi.com.sa/collections/tipping-cylinders-mh
