MH Tipping Cylinder MHC129-3-3850

Heavy-Duty Hydraulic Tipping Cylinder – 3850mm Stroke

Designed for reliable performance in medium to heavy-duty tipping applications, this hydraulic cylinder from MH Hydraulics is perfect for 2- to 4-axle dump trucks and trailers. With a stroke length of 3850 mm and a maximum working pressure of 200 bar, it offers the power and durability required for daily operations in tough environments.

• Stroke: 3850 mm

• Maximum Pressure: 200 bar

• Oil Volume: 43L (extend) / 39L (retract)

• Cylinder Weight: 230 kg

• Tipping Capacity: 32 to 35 tons

Key Features:

• Ideal for construction, mining, and transport sectors

• High-strength steel construction for long service life

• Designed for quick installation and easy maintenance

• Supports high-pressure systems for fast and efficient tipping

This model belongs to our RHINO Series of tipping cylinders - Built Strong. Made to Last.
Available for fast delivery from our warehouses in Dammam and Riyadh.

🔧 Need custom-built hydraulic cylinders? We manufacture and repair cylinders to your specifications.

🛒 Learn more or shop now: https://hfi.com.sa/collections/tipping-cylinders-mh
